Welding fumes extraction unit

SRF SmartFil

The mobile professional extraction system for regular use

2.989,00 EUR excl. Tax / pc(s).
3.586,80 EUR incl. 20% Tax / pc(s).

Prices are recommended retail prices. Retailer prices may vary.

Art.-No. 1800031

Are you interested in this product?
  • Put a request
  • Find Trader
  • Productdetails

    • Application range: Medium smoke/dust volumes with regular use at changing workplaces.
    • Compact and stable design
    • Safe operation due to rotating field detection
    • Three meter extraction arm
    • Less tracking of the extraction arm due to flow-optimized design of the extraction hood
    • Suction hood with throttle valve can be rotated 360 degrees
    • Increased safety due to filter monitoring and contamination-free filter replacement
    • High efficiency due to large capacity and long filter service life
    • Filter area of the replacement filter 42 square meters
    • Quality Made in Germany



    • Safe operation due to rotating field detection
    • Less tracking of the extraction arm thanks to the flow-optimized design of the extraction hood
    • Increased safety through filter monitoring
    • High efficiency thanks to large capacity and long filter life



    Dimensions and weights
    Length approx.795 mm
    Width/depth approx.836 mm
    Height approx.1169 mm
    Weight approx.131 kg
    Electrical Data
    Drive motor output1,5 kW
    Supply voltage400 V
    Mains frequency50 Hz
    Extraction
    Max. extraction performance1100 m³/h
    Extraction arm typeHose design
    Extraction hood length360 mm
    Extraction hood width295 mm
    Fan typeRadial ventilator
    Filter
    Filtering process2-stage
    Area approx.25 m²
    Noise emission
    Sound pressure level70 dB(A)
    VPE1
    Unit: pc(s).
    Packaging unit: 1



    3m Extraction arm
